Model: BR48XCB-N | 1920×360 | 700 Nits | Dual HDMI
The Brownopto BR48XCB-N is a 47.6-inch strip-type advertising screen engineered for high-impact digital signage in narrow or vertical spaces. With a display area of 1189.44mm (H) × 223.02mm (V), this sleek bar display delivers exceptional visibility in retail storefronts, elevator lobbies, transportation hubs, and office corridors.
Featuring an ultra-bright 700 cd/m² WLED backlight, this screen ensures outstanding clarity and visibility even in brightly lit indoor environments. Whether mounted near windows or under strong ceiling lights, your content remains vivid and attention-grabbing. The panel offers a high 1200:1 contrast ratio and 16.7 million colors (69% NTSC), producing rich, dynamic visuals that enhance brand engagement.
With a wide 178° viewing angle (CR≥10) on all sides, the BR48XCB-N provides consistent image quality from multiple viewing positions—ideal for installations in open-plan spaces or narrow passageways. The screen has a long operational lifespan of 50,000 hours, ensuring reliable performance in 24/7 commercial environments.
This model supports flexible connectivity with dual HDMI inputs, allowing seamless switching between two video sources. Additional interfaces include USB, SD card slot, CVBS input, headphone jack, and power port, making it compatible with a wide range of media players and control systems. It operates on universal AC 100–240V (50/60Hz) power, simplifying deployment across global markets.
With a slim profile of only 35.23mm depth and a lightweight design (≤7.5kg), the BR48XCB-N is easy to mount and integrates seamlessly into modern architectural environments. Its robust construction ensures durability in demanding commercial settings.
📏 47.6 INCH Strip Design
Ideal for narrow walls, elevators, and vertical digital signage
💡 700 Nits High Brightness
Perfect for bright retail and public indoor environments
🔌 Dual HDMI Inputs
Supports two video sources for flexible content control
🌐 Universal Power Input
AC 100–240V compatible for global deployment
Technical Specifications
| Model | BR48XCB-N |
| Display Size | 47.6 inch |
| Display Area | 1189.44(H) × 223.02(V) mm |
| Resolution | 1920 × 360 |
| Brightness | 700 cd/m² |
| Contrast Ratio | 1200:1 |
| Viewing Angle | 89°/89°/89°/89° (CR≥10) |
| Color Depth | 16.7 million colors (69% NTSC) |
| Backlight | WLED |
| Frame Rate | 60 Hz |
| Lifespan | 50,000 hours |
| Resolution Ratio | 1920(H) × 360(V) |
| Interfaces | 2×HDMI IN, USB, SD card slot, CVBS, headphone jack, power port |
| Power Input | AC 100–240V (50/60Hz) |
| Power Consumption | ≤60W |
| Dimensions | 1196.64 × 248.82 × 35.23 mm |
| Net Weight | ≤7.5 kg |
| Operating Temp. | 0°C ~ 50°C |
| Storage Temp. | -20°C ~ 60°C |
| Certifications | CE, FCC |
| Warranty | 1 year |
Ideal Applications
Retail Stores: Wall-mounted promotions, brand messaging, and product highlights
Elevator Lobbies: Vertical or horizontal digital ads in high-traffic zones
Transit Stations: Train/bus arrival info, safety messages, and advertising
Office Buildings: Welcome screens, wayfinding, and internal communications
Hotels & Restaurants: Menu boards, ambiance videos, and event promotions
Need a 47.6 INCH Strip Display?
We offer OEM/ODM services, bulk pricing, and technical support.
Contact Us Today
