High-Brightness 29 Inch Touchscreen Digital Signage

Model:BR29XCB-T Size:29inch Display Type:BAR Touchscreen:CTP Interface:USB Resources: 29 Inch High-Brightness Touchscreen Advertising Screen

Inquiry Custom

DESCRIPTION

Model: BR29XCB-T | 700 Nits | 1920×540 | Capacitive Touch

The Brownopto BR29XCB-T is a 29-inch ultra-wide high-brightness touchscreen display built for demanding commercial and industrial applications. With a powerful 700 cd/m² brightness, it delivers excellent visibility even in brightly lit environments—perfect for retail stores, kiosks, factories, and public information centers.

Featuring a unique 1920×540 resolution and a wide 720.8mm form factor, this display offers more vertical space than standard 16:9 screens, ideal for interactive menus, digital signage, real-time data dashboards, or multi-row content. The **10-point capacitive G+G touchscreen** ensures smooth, responsive touch interaction, making it perfect for self-service kiosks, wayfinding systems, and customer engagement terminals.

Equipped with rich connectivity including dual HDMI 1.4b ports (4K@30Hz), CVBS (mini-AV), USB 2.0, SD card, headphone jack, and DC 12V power input, the BR29XCB-T supports flexible integration with PCs, media players, and embedded systems. Its rugged design, 50,000-hour lifespan, and wide operating temperature make it a reliable choice for 24/7 operation in harsh environments.

💡 700 Nits High Brightness

Clear visibility under strong ambient light and near windows

🖥️ 29" 1920×540 Display

Extra-wide format for more content, ads, or real-time data

👆 Capacitive G+G Touch

Smooth, durable 10-point touch for kiosks and interactive apps

🔌 Dual HDMI & Multi-Interface

Supports 4K@30Hz input, CVBS, USB, SD, and audio output

Technical Specifications

Model	BR29XCB-T
Display Size	29 inch
Display Area	709.84(H) × 202.22(V) mm
Resolution	1920 × 540
Brightness	700 cd/m²
Contrast Ratio	1200:1
Viewing Angle	89°/89°/89°/89° (CR≥10)
Color Depth	16.7M, 72% NTSC
Backlight	WLED
Touchscreen	Capacitive G+G, 10-point touch
Frame Rate	60 Hz
Response Time	15ms (G to G)
Lifespan	50,000 hours
Interfaces	HDMI×2, CVBS (mini-AV), USB 2.0, SD card, USB (Touch), Headphone, DC 12V (Type-C)
Video Input	Dual HDMI 1.4b, supports 4K@30Hz decoding
Audio Output	3.5mm headphone jack (amplifier mutes when used)
Power Input	DC 12V via Type-C
Power Consumption	≤40W
Dimensions	720.8 × 226.25 × 40.3 mm
Net Weight	≤6 kg
Operating Temp.	0°C ~ 50°C
Storage Temp.	-20°C ~ 60°C
Certifications	CE, FCC
Warranty	1 year

Ideal Applications

Interactive Kiosks: Self-service check-in, ordering, or information terminals
Retail Stores: Touch-enabled digital signage, product catalogs, promotions
Industrial HMI: Machine control panels, factory monitoring systems
Transportation: Wayfinding, ticketing, and arrival/departure boards
Corporate Lobbies: Interactive welcome screens and directory systems
