23.1INCH Android Bar Display 700 Nits | BR23X1B-N | Brownopto

Model:BR23X1B-N Size:23.1inch Display Type:BAR Touchscreen:NO Interface:USB Resources: 23.1 INCH Strip Type Advertising Screen

Inquiry Custom

DESCRIPTION

Model: BR23X1B-N | 700 Nits | 1920×158 Resolution | Android 8.1

The Brownopto BR23X1B-N is a 23.1-inch ultra-narrow bar display designed for high-visibility digital signage in retail, transportation, and public spaces. With an exceptional brightness of 700 cd/m², this display ensures clear readability even under direct indoor lighting or near windows—making it ideal for price strips, arrival boards, and dynamic branding.

Running on Android 8.1 with a Rockchip PX30 Quad-Core processor, it supports seamless playback of videos, images, text, and web content. Integrated 2.4GHz WiFi and Bluetooth 4.0 enable remote content updates, scheduled power control, and centralized management across multiple units via cloud-based software.

📏 23.1" Bar Display

Ultra-long format for seamless integration above shelves or doors

💡 700 Nits Brightness

Sunlight-readable performance in bright indoor environments

🤖 Android 8.1 OS

Supports apps, web pages, and OTA content updates

📡 Remote Management

Schedule playback, power on/off, and monitor status remotely

Technical Specifications

Model	BR23X1B-N
Display Size	23.1 inch
Display Area	585.216(H) × 48.1584(V) mm
Resolution	1920 × 158
Brightness	700 cd/m²
Contrast Ratio	1000:1
Viewing Angle	85°/85°/85°/85° (CR≥10)
Color Depth	16.7M, 72% NTSC
Processor	Rockchip PX30 Quad-Core A35
Operating System	Android 8.1
RAM	1GB
Built-in Storage	8GB (up to 64GB optional)
External Storage	Up to 64GB TF card
Connectivity	2.4GHz WiFi, Bluetooth 4.0
Power Input	DC 12V via Type-C
Power Consumption	≤18W
Dimensions	597.2 × 61.8 × 15 mm
Net Weight	0.65 kg
Certifications	CE, FCC
Warranty	1 year
