Explore real-world examples of how TFT and OLED displays have been successfully integrated into various applications, from digital signage to industrial controls. Learn from these case studies to inspire your next project.
Miniature. Precise. Powerful. (1" – 11.9")
Brownopto specializes in miniature OLED and TFT LCD display cases for space-constrained and high-precision applications. With sizes ranging from 1 inch to 11.9 inches, our displays are ideal for portable medical devices, industrial HMIs, smart home panels, and embedded systems. Combining high resolution, ultra-low power, and rugged reliability, Brownopto delivers visual performance where every millimeter counts.
Miniaturized Design: Compact form factors from 1" to 11.9", ideal for handheld and embedded devices.
High Pixel Density: Up to 400 PPI for crystal-clear text and graphics on small screens.
Low Power Consumption: OLED models use no backlight (saves power); TFTs optimized with LED drivers for efficiency.
OLED Advantages: True blacks, infinite contrast, faster response, and flexible PCB options.
TFT LCD Advantages: High brightness, excellent color stability, and cost-effective scaling.
Rugged Build: Resistant to shock, vibration, and temperature extremes – suitable for industrial and outdoor use.
Medical Devices: Patient monitors, infusion pumps, portable ultrasound, glucose meters.
Industrial Controls: Handheld testers, PLC interfaces, robotics, sensor displays.
Smart Home & IoT: Touch panels, security systems, appliance UIs, voice assistants.
Consumer Electronics: Wearables, POS terminals, gaming accessories, diagnostic tools.
| Parameter | OLED Display Cases | TFT LCD Display Cases |
|---|---|---|
| Size Range | 1" – 7" | 1" – 11.9" |
| Display Type | Passive/Active Matrix OLED | IPS / TN / FF-S TFT LCD |
| Resolution Options | 128x64, 240x240, 320x320, 480x480, 720x720 | 240x320, 480x800, 800x1280, 1080x1920 (FHD) |
| Brightness | 150–400 cd/m² (typical) | 300–800 cd/m² (sunlight readable up to 1200) |
| Contrast Ratio | 100,000:1 – ∞:1 (true black) | 700:1 – 1500:1 |
| Viewing Angle | 178° (all directions) | 170°–178° (IPS models) |
| Interface Options | 8080/6800 Parallel, SPI, MIPI, I²C | RGB, MCU, LVDS, MIPI DSI |
| Operating Temp | -30°C to +70°C | -20°C to +70°C |
| Certifications | RoHS, CE, REACH | RoHS, CE, REACH, ISO 13485 (medical variants) |
| Customization | Custom glass, flex PCB, bezel, touch overlay | Optical bonding, touch (resistive/capacitive), backlight tuning |
Client: Global medtech startup developing handheld ultrasound probes.
Solution: Integrated 3.5" Brownopto OLED display (320x320) into ergonomic probe handle for real-time imaging.
Result: 40% longer battery life vs. previous TFT design, improved image contrast in field conditions, and faster time-to-market with 7-day sample delivery.
Free Design-In Support: Application engineering for layout, power, and signal integrity.
Fast Sampling: 5–7 day turnaround for standard and custom models.
Volume Production: Scalable manufacturing from 1K to 1M units/month.
Global Logistics: DDP shipping to USA, Europe, China, Japan, and Southeast Asia.
Warranty: 3-year standard; extended options available for medical and automotive clients.
Brownopto BR548105-A1: 5.48" AMOLED module with 1080×1920 resolution, LTPS backlight, MIPI 4 Lane interface. Industrial-grade performance (-30°C to +80°C),...
Brownopto's 6.01" AMOLED module (BR601108-A1) features 1080x2160 resolution, 800cd/m² brightness, MIPI 4-lane interface, -20°C~+70°C operation, and 10,000:...
Case SummaryThis case study explores how SUNMI, a leading IoT technology company specializing in smart commercial hardware, incorporates displays from Gaozhan O...
Case SummaryThis detailed case study highlights a Panasonic smart door entry phone system that features our 7-inch main display and 2.2-inch and 2.4-inch sub-di...
Case SummaryThis case study explores how Baidu's Xiaodu at Home, a leading smart video speaker, incorporates displays from our company to enhance the user exper...
Case SummaryThis case study examines how Pax, the world's largest POS terminal supplier, utilizes LCD and touchscreen displays from our company to enhance the f...
Case SummaryThis case study examines how Vtech, the world's largest provider of infant and preschool electronic learning products, utilizes LCD and touchscreen ...
Case SummaryThis case study explores how FLYAUDIO, a leading manufacturer of car audio equipment and automotive electronics, incorporates displays from Gaozhan ...
Case SummaryThis case study explores how Nobo Auto, a subsidiary of Great Wall Motors, incorporates 12.3-inch screens from Gaozhan Optoelectronics into their ca...
Case SummaryThis case study examines the partnership between UNI-T , a leading manufacturer of electronic testing equipment, and your company, which provides di...
Case SummaryThis case study explores how Casarte, a premium appliance brand under Haier, incorporates 6.86-inch screens from our company into their refrigerator...
Case SummaryThis case study explores how Fuji Electric's FRENIC-MEGA series general-purpose inverter incorporates a 7-inch screen from our company to enhance us...
