Model: BR29XCB-N | 700 Nits | 1920×540 | Android 8.1
The Brownopto BR29XCB-N is a 29-inch ultra-wide high-brightness advertising display engineered for demanding indoor environments such as retail stores, transportation hubs, factories, and public signage. With a powerful 700 cd/m² brightness, this display delivers exceptional visibility even under strong ambient light—perfect for near windows, bright lobbies, or industrial settings.
Featuring a unique 1920×540 resolution and a sleek 720.8mm width, it offers more vertical space than standard 16:9 screens, ideal for displaying multi-row content, scrolling text, product details, or real-time data feeds. Powered by Android 8.1 and a Rockchip PX30 Quad-Core processor, it supports smooth playback of videos, web pages, images, and dynamic content. With built-in 2.4GHz WiFi and Bluetooth 4.0, it enables remote content updates, scheduled on/off, and centralized fleet management via cloud software.
Designed for reliability, the BR29XCB-N supports 7×16 hours of continuous operation and comes with rich interfaces including RJ45, USB, TF card, and headphone jack—making it a versatile solution for commercial digital signage.
💡 700 Nits High Brightness
Clear visibility in bright indoor environments and near windows
📺 29" 1920×540 Display
Wider format for more content, ideal for ads and real-time data
🤖 Android 8.1 OS
Supports apps, web content, and OTA updates for flexible deployment
📡 Remote Management
Schedule content, power control, and monitor status across fleets
Technical Specifications
| Model | BR29XCB-N |
| Display Size | 29 inch |
| Display Area | 709.84(H) × 202.22(V) mm |
| Resolution | 1920 × 540 |
| Brightness | 700 cd/m² |
| Contrast Ratio | 1200:1 |
| Viewing Angle | 178°(H) × 178°(V) |
| Color Depth | 16.7M, 72% NTSC |
| Backlight | WLED |
| Processor | Rockchip PX30 Quad-Core A35 |
| Operating System | Android 8.1 |
| RAM | 1GB |
| Built-in Storage | 8GB (optional 16/32/64GB) |
| External Storage | Up to 64GB TF card |
| Connectivity | 2.4GHz WiFi, Bluetooth 4.0, RJ45 (100M) |
| Interfaces | RJ45, USB 2.0, USB 1.0 (OTG), TF, Headphone, DC 12V |
| Power Input | DC 12V |
| Power Consumption | ≤30W |
| Dimensions | 720.8 × 226.5 × 40.2 mm |
| Net Weight | ≤4.4 kg |
| Lifespan | 50,000 hours |
| Certifications | CE, FCC |
| Warranty | 1 year |
Ideal Applications
Retail Stores: Wide-format digital signage above counters or entrances
Transit Hubs: Train/bus arrival boards, platform indicators, service alerts
Industrial Sites: Factory status displays, production line monitoring
Corporate Offices: Lobby welcome screens, meeting room schedules
Digital Menus: Full-width menu boards in restaurants and cafes
Looking for a High-Brightness Display?
We offer bulk pricing, OEM services, and custom firmware solutions.
Request a Quote
